Intelligence that takes shapes. Shape intelligence for agent platforms.
View controls
Loading the interactive study. A static illustration is available.
Change the part.
The shape is there. Editable features and design requirements are often missing. Before the next change, teams have to bring that context back together.
Join the waitlist
Harness Mesh to CAD
Harness Keep references, dimensions, and hard constraints with your agents as they work through each revision.
Describe the next change…
Preview with SolidWorks, Google Drive, Fusion and Autodesk icons. Tool connections are illustrative.
See the workflow
Make it yours.
Start with existing geometry.
An STL mesh or CAD model gives a design task its starting point.
Keep constraints in view.
Bring project references, specifications, and dimensions that must stay fixed.
Specify the next revision.
Describe what should change and what must stay fixed as the design evolves.
Inspect the result.
Review geometry, dimensions, and drawings before the next revision.
V12-60 engine 149 parts
Technical drawing of piston R1 {"schema": "cad.drawing.v1", "part_id": "piston-r1", "label": "Piston R1", "model_version": "v2-069db2c8", "source_sha256": "26ecd609e6b2970980351e93b2c2b6067e7b0b993e7ed83c0d6ff5b52b3ebd61", "units": "mm", "projection": "first-angle (ISO 5456-2)", "sheet": {"size": "A3", "mm": [420.0, 297.0]}, "scale": [1, 1], "scale_text": "1:1", "views": {"front": {"right": [1, 0, 0], "up": [0, 0, 1], "extent": [-42.900000000000006, 42.900000000000006, 0.0, 60.00000000000003], "origin": [123.74999999999999, 63.99999999999997], "scale": 1.0, "linework": {"visible": 37, "hidden": 42}}, "top": {"right": [1, 0, 0], "up": [0, 1, 0], "extent": [-42.900000000000006, 42.900000000000006, -42.90000000000001, 42.90000000000001], "origin": [123.74999999999999, 137.0], "scale": 1.0, "linework": {"visible": 5, "hidden": 86}}, "left": {"right": [0, -1, 0], "up": [0, 0, 1], "extent": [-42.90000000000001, 42.90000000000001, 0.0, 60.00000000000003], "origin": [233.65, 63.99999999999997], "scale": 1.0, "linework": {"visible": 40, "hidden": 25}}}, "identity_base_version": null, "title_block": {"drawing_number": "piston-r1@v2-069db2c8", "revision": "v2", "date_of_issue": "2026-10-23", "sheet": "1/1", "size": "A3", "scale": "1:1", "units": "mm", "creator": "Studio editor build · user not recorded", "checked": "", "approved": "", "material": "未指定 / unspecified", "model_version": "v2-069db2c8", "parent_version": "v0", "identity_base_version": "none", "source_sha256": "26ecd609e6b2"}, "holes": [{"view": "top", "count": 2, "callout": "2× Ø28 ↧1", "ids": ["piston-r1/h1", "piston-r1/h2"], "labels": ["h1", "h2"], "ambiguous": {}, "entries_mm": [[-15.0, 18.0, 60.0], [15.0, 18.0, 60.0]]}, {"view": "top", "count": 2, "callout": "2× Ø33 ↧1", "ids": ["piston-r1/h3", "piston-r1/h4"], "labels": ["h3", "h4"], "ambiguous": {}, "entries_mm": [[-17.0, -18.0, 60.0], [17.0, -18.0, 60.0]]}, {"view": "left", "count": 2, "callout": "2× Ø22.1 PARTIAL BORE L31.4", "ids": [], "labels": ["p1", "p2"], "ambiguous": {}, "entries_mm": [[-11.5, 0.0, 28.0], [42.9, 0.0, 28.0]]}], "overall_mm": [85.8, 85.8, 60.0]}
